Legrand KEOR MOD
The Legrand Keor MOD UPS (uninterruptible power supply) is a three phase system supplying online double conversion with PWM high frequency technology. The award winning modular technology delivers rated power from 25kVA to 250kVA, each unit can be paralleled to identical or different units up to 600kW with the possibility to have N+X redundancy.
Overview
An ideal solution for all critical computer applications including data centres, the KEOR MOD uses VRLA sealed batteries which are arranged inside the UPS up to 125kW.
Key Features
Additional Features
- Internal Backup time up to 125 KW
- Reduced battery charging times
- Double conversion efficiency up to 96.8% (power module efficiency)
- Efficiency in ECO mode up to 99%.
- Output power factor = 1
- Modular redundancy in N+1 configuration
- Hot-swappable modules
- Parallelable system up to 24 power modules
- Multicoloured status bar LED
- Intelligence distributed between modules
Technical Specification
| RATING | 25-250kVA |
| RATING KVADIMENSIONS (WxDxH) | 600W x 970D x 1990H |
| INPUT PHASE | Three Phase |
| INPUT VOLTAGE | 400V 3F+N+PE |
| INPUT VOLTAGE TOLERANCE RANGE | 400V +15%/-20% |
| INPUT FREQUENCY | 45-65 Hz |
| OUTPUT OUTPUT PHASE | Three Phase |
| PARALLEL | Up to 1.2MW across 2 cabinets (100kW in 3U) |
| OUTPUT POWER FACTOR | 1 |
| OUTPUT WAVEFORM | Sinusoidal |
| OUTPUT VOLTAGE | 380/400/415VAC |
| OUTPUT FREQUENCY | 50/60 Hz selectable by the user ±2 % (standard), ±14 % (extended) |
| OUTPUT EFFICIENCY | Up to 97% |
| BATTERY RUNTIME | Dependent on battery capacity |
| BATTERY DC VOLTAGE | 12 V, 9 Ah - 11 Ah |
| BATTERY CHARGE CAPACITY | Smart charge technology. 3-stage advanced cycle |
| OPERATING TEMPERATURE TOLERANCE | 0 - 40°C |
| RELATIVE HUMIDITY | <95% (non-condensing) |
| COMMUNICATION | 2x RS485 ports (one for external accessories), 11 input floating contacts, 8 output floating contacts, 1 interface slot, USB host port |
| PARALLEL | N+X |
| FUNCTIONS | Controlled noise level, Multicoloured status bar LED, Parallelable system up to 24 power modules, Hot-swappable modules, Decentralised by-pass, Intelligence distributed between modules |
